Conveying Vessel

Product Description

Conveying Vessel

We have put forth for our clients a high quality Conveying Vessel to our clients. The offered vessel is comprises with single piece of body, inlet aperture, horizontal inlet and outlet aperture for conveying material. Fully enclosed conveying system, this vessel is used for transferring ash through standard pipelines at low velocity. Excellent quality raw materials and the latest techniques are utilized in the manufacturing process of this vessel by our seasoned professionals. Clients can avail this Conveying Vessel in both standard and customize options at most affordable price range.

Key Features:

Specifications:

The Ash Vessel operates on the principle of Dense Phase Pneumatic Conveying System, i.e. a high pressure, dense material air mixture at a low velocity moving through the conveying pipe in separate batches or plugs. Dust-less, fully enclosed conveying system that is economical and environmentally sustainable. The Ash Vessel comprises one piece body with a top inlet aperture and horizontal inlet and outlet aperture for conveying material. Mounted on the top inlet is a specially designed OSME Engineering dome Valve. It has a controlled air supply for conveying the material.

These vessels can be combined in series comprising 2, 3 or 4 vessels with common conveying pipeline, thus resulting in low capital equipment cost without affecting the performance of the system. Uniquely designed specifically to handle multiple feed points below equipment such as ESPs and Baghouse. Multiple feed points can be arrangement on ONE PIPELINE with Ashveyor.
